Battery Charger - WP2s Full Set - by XTAR
Battery Charger - WP2s Full Set - by XTAR

Alternative Views:

Our Price including GST: $39.00

Product Code: WP2S-FULL-SET

Description 100-240VAC (World Voltage) / 12VDC input independent channel 1-2 cell lithium ion battery charger. Also can be used as portable charger with 2.1A output USB output
Brand XTAR
Width 60mm
Height 35mm
Length/Breadth/Depth 120mm
Weight 81g

XTAR WP2s 100-240VAC (World Voltage) / 12VDC input independent channel 2 cell lithium ion battery charger.

  • Comes with SAA, MEPS approved 100-240VAC (world voltage) to 12VDC input power adaptor plus 12VDC input cigarette light connection car plug.
  • Two cell charger with independent channels to charge one or two lithium ion cells in sizes 10440, 14500, 14650, 15270, 16340, 18500, 17670, 18650, 18700 commonly used in LED torches, E-Cig's & other devices.
  • To view the complete range of torch and laser sight batteries we have available please click this link.
  • Three selectable charging currents
    • 250mA (±30mA)
    • 500mA (±50mA)
    • 1000mA (±80mA)
  • Charge re-activation if cell voltage drops below 3.9V if cells left in the charger. Ensures cells are always ready for use.
  • Over discharged cell recovery (cell voltage <2.0V). (Percentage of capacity recovery dependant on cell health).
  • Algorithm based TC/CC/CV charging system with reverse polarity & overcharge protection.
    • CC cut-off voltage 4.2V ±0.05V
    • CV cut-off current <100mA
    • TC current (battery voltage 2.0V~3.0V) 80mA(±20mA)

The charger can also be used as a portable charger with USB power output @ 5V 2.1A.

  • Cable & connector options available Via this link
  • When used as a portable charger via USB output the product also uses overdischarge disconnection technology to prevent overdischarge (2.8V ±0.15V) of the lithium ion cell being used as the power source.
  • 2 year repair warranty (when used according to specification & in normal conditions)

Full specifications available by downloading the datasheet below

Data Sheet WP2s Full Set.pdf
